ALPC2

ALPC2 – directly plug in mouse and calibrate using the computer software

Laser Power Calibration Application has user-friendly PC application ease end-user in controlling and performing the laser power calibration process.
This application provides options for user to define the setting and pass-fail criteria for the calibration process.

USB to SPI adapter kit provides the interface between laser power calibration application and mouse target board hardware. Use SPI (Serial Peripheral Interface) to communicate with target mouse board hardware.

Optical Power Meter & Sensor measures the laser output power reading. Additional power meter can be supported by adding new driver to the laser power calibration application.

Mechanical Jig provides mounting for optical sensor and mouse mounting stage. The mechanical jig contains both X and Y displacement lever to adjust the mouse laser output to the optical sensor input.
